HYUNDAI 70D-7E BRAKE & INCHING LINKAGE
| # | Part No. | Description | Qty |
|---|---|---|---|
| 0 | 31******00 | MAIN CONTROL VALVE | 1 |
| 0 | 31******01 | MAIN CONTROL VALVE | 1 |
| 0 | 31******00 | MAIN CONTROL VALVE | 1 |
| 0 | 31******01 | MAIN CONTROL VALVE | 1 |
| 0 | 31******00 | MAIN CONTROL VALVE | 1 |
| 0 | 31******01 | MAIN CONTROL VALVE | 1 |
| 0 | 32******50 | O-RING | 2 |
| 0 | 32******00 | O-RING | 1 |
| 0 | 32******10 | O-RING | 1 |
| 0 | 32******20 | O-RING | 1 |
| 0 | 32******90 | O-RING | 1 |
| 0 | 32******70 | PILOT-POPPET | 1 |
| 0 | 32******80 | O-RING | 1 |
| 0 | 32******60 | SPRING-RELIEF | 1 |
| 0 | 32******90 | O-RING | 1 |
| 0 | 32******40 | PLUG-RELIEF | 1 |
| 0 | 32******30 | NUT | 1 |
| 0 | 32******20 | PISTON-RELIEF | 1 |
| 0 | 31******10 | KIT-SEAL(SPOOL) | 1 |
| 0 | 31******00 | SEAL KIT | 1 |
| 1 | 32******10 | LIFT BLOCK ASSY | 1 |
| 1 | XK******71 | LIFT BLOCK ASSY | 1 |
| 1 | 32******10 | LIFT BLOCK ASSY | 1 |
| 1 | XK******71 | LIFT BLOCK ASSY | 1 |
| 1 | 32******10 | LIFT BLOCK ASSY | 1 |
| 1 | XK******71 | LIFT BLOCK ASSY | 1 |
| 2 | 31******10 | TILT BLOCK ASSY | 1 |
| 2 | XK******72 | TILT BLOCK ASSY | 1 |
| 2 | 31******10 | TILT BLOCK ASSY | 1 |
| 2 | XK******72 | TILT BLOCK ASSY | 1 |
| 2 | 31******10 | TILT BLOCK ASSY | 1 |
| 2 | XK******72 | TILT BLOCK ASSY | 1 |
| 3 | 32******40 | PLUG | 1 |
| 4 | 31******20 | PLUG-BLIND | 2 |
| 5 | 31******30 | BOLT-LONG | 4 |
| 6 | 32******70 | PLUG-HYDROSTAT | 1 |
| 7 | 32******80 | O-RING | 1 |
| 8 | 32******90 | SPRING-HYDROSTAT | 1 |
| 9 | 32******00 | SLEEVE-HYDROSTAT | 1 |
| 10 | 32******10 | O-RING | 1 |
| 12 | 32******80 | BLIND PLUG-ORIFICE | 1 |
| 12 | XK******70 | BLIND PLUG-ORIFICE | 1 |
| 12 | 32******80 | BLIND PLUG-ORIFICE | 1 |
| 12 | XK******70 | BLIND PLUG-ORIFICE | 1 |
| 12 | 32******80 | BLIND PLUG-ORIFICE | 1 |
| 12 | XK******70 | BLIND PLUG-ORIFICE | 1 |
| 16 | 32******30 | RETAINER | 1 |
| 17 | 32******40 | PLUG-BLIND | 1 |
| 18 | 32******50 | BALL-STEEL | 1 |
| 19 | 32******60 | SPRING | 1 |
| 20 | 32******70 | SPRING | 1 |
| 22 | 32******00 | PLATE-SIDE | 1 |
| 30 | 32******10 | SEAT | 1 |
