HYUNDAI 20D-7E CONTROL VALVE ASSY(NEW)
| # | Part No. | Description | Qty |
|---|---|---|---|
| 0 | F1*****42 | WHEEL BRAKE ASSY-LH | 1 |
| 0 | F1*****52 | WHEEL BRAKE ASSY-RH | 1 |
| 1 | BD********01 | BACK PLATE ASSY-LH | 1 |
| 1 | BD********02 | BACK PLATE ASSY-RH | 1 |
| 2 | BD********02 | LIND SHOE ASSY | 2 |
| 3 | BD********01 | WHEEL CYLINDER ASSY | 1 |
| 4 | 3B****99 | BOLT-SET | 2 |
| 5 | BD********01 | ADJUSTER ASSY-LH | 1 |
| 5 | BD********02 | ADJUSTER ASSY-RH | 1 |
| 6 | BD********01 | PIN-S/HOLE DOWN | 4 |
| 7 | 3B****60 | SPRING | 4 |
| 8 | 3B****81 | WASHER | 7 |
| 9 | BD********01 | BUSH | 1 |
| 10 | BD********01 | PLATE-SHOE GUIDE | 1 |
| 11 | BD********01 | LEVER-LH,ACTUATOR | 1 |
| 11 | BD********01 | LEVER-RH,ACTUATOR | 1 |
| 12 | BD********01 | LEVER-LH,PAWL | 1 |
| 12 | BD********01 | LEVER-RH,PAWL | 1 |
| 13 | BD********01 | STOPPER | 1 |
| 14 | BD********01 | SPRING-SHOE ADJ/END | 1 |
| 15 | BD********02 | RING-RETAINING | 1 |
| 16 | BD********01 | STRUT | 1 |
| 17 | BD********01 | SPRING-STRUT | 1 |
| 18 | BD********01 | CABLE ASSY-PARKING,LH | 1 |
| 18 | BD********02 | CABLE-PARKING ASSY/RH | 1 |
| 19 | 2B****65 | PLUG | 4 |
| 20 | BD********01 | SPRING-LEVER PAWL | 1 |
| 21 | 3B****63 | SCREW-BLEED | 1 |
| 22 | 4B****65 | CAP-BLEED SCREW | 1 |
| 23 | 2B****52 | PLUG-PROTECT | 1 |
| 24 | BD********01 | LEVER-LH/PARKING | 1 |
| 24 | BD********02 | LEVER-RH/PARING | 1 |
| 25 | BD********01 | PIN-LEVER | 1 |
| 26 | BD********01 | RING-RETAINING | 1 |
| 27 | BD********01 | SLEEVE-ANCHOR | 1 |
| 28 | DM********01 | BOLT | 1 |
| 29 | 4B****41 | WASHER-SPRING | 1 |
| 30 | BD********00 | SPRING-A/SHOE R | 1 |
| 31 | BD********00 | SPRING-B/SHOE R | 1 |
