HYUNDAI R170W-7A SWING REDUCTION GEAR(TYPE 1)
| # | Part No. | Description | Qty |
|---|---|---|---|
| 0 | 31******10 | BUCKET CYLINDER ASSY | 1 |
| 0 | XK******31 | SEAL-BUFFER | 1 |
| 0 | XK******32 | U-PACKING | 1 |
| 0 | XK******33 | RING-BACK UP | 1 |
| 0 | XK******34 | WIPER-DUST | 1 |
| 0 | XK******36 | O-RING | 1 |
| 0 | XK******37 | RING-BACK UP | 1 |
| 0 | XK******38 | O-RING | 1 |
| 0 | XK******41 | SEAL-PISTON | 1 |
| 0 | XK******42 | RING-WEAR | 2 |
| 0 | XK******43 | RING-DUST | 2 |
| 0 | XK******44 | O-RING | 1 |
| 0 | XK******45 | RING-BACK UP | 2 |
| 0 | XK******99 | O-RING | 1 |
| 0 | XK******32 | U-BOLT | 3 |
| 1 | XK******25 | TUBE ASSY | 1 |
| 2 | XK******09 | BUSHING-PIN | 1 |
| 3 | XK******26 | ROD ASSY | 1 |
| 4 | XK******09 | BUSHING-PIN | 1 |
| 5 | XK******27 | COVER-ROD | 1 |
| 6 | XK******29 | BUSHING-ROD | 1 |
| 7 | XK******30 | RING-RETAINING | 1 |
| 12 | XK******35 | RING-RETAINING | 1 |
| 16 | XK******39 | RING-CUSHION | 1 |
| 17 | XK******40 | PISTON | 1 |
| 23 | XK******46 | NUT-PISTON | 1 |
| 24 | XK******47 | SCREW-SET | 1 |
| 25 | XK******50 | BOLT-HEX SOCKET | 14 |
| 26 | XK******28 | BAND ASSY-H | 1 |
| 27 | XK******57 | BAND-PIPE | 2 |
| 28 | XK******59 | BOLT-HEX | 4 |
| 29 | XK******58 | WASHER-SPRING | 4 |
| 30 | XK******29 | BAND ASSY-R | 1 |
| 31 | XK******30 | PIPE ASSY-H | 1 |
| 33 | XK******00 | BOLT-HEX SOCKET | 8 |
| 34 | XK******58 | WASHER-SPRING | 8 |
| 35 | XK******31 | PIPE ASSY-R | 1 |
| 36 | XK******99 | O-RING | 2 |
| 38 | XK******33 | NUT-HEX | 6 |
| 39 | XK******58 | WASHER-SPRING | 6 |
| 40 | XK******37 | WIPER-PIN | 4 |
| 42 | XK******84 | DUST COVER | 2 |
| 43 | XK******85 | HEX BOLT | 8 |
